DR-CG-2309-002-B-PT DR-CG-2309-002-B-PT Dura-Lite USA Plastic Tank/ Aluminum Core Radiator - No Frame - With Oil Coolers (Driver Side - Engine Oil Cooler with ¾” ORB Fittings on 7” [177.8mm] centers and Passenger Side - Transmission Oil Cooler with 1 1/16” ORB Fittings on 18” [457.2mm] centers) - With Filler Neck (Passenger Side top corner), 1/8” NPT Low Coolant Sensor Fitting, and ¾” NPT Low Coolant Sensor Fitting..
Dura-Lite™ Radiator - No Frame - Oil Coolers (1 Year Warranty)

DR-CG-2309-002-B-PT

DR-CG-2309-002-B-PT
DR-CG-2309-002-B-PT

Description

Plastic Tank/ Aluminum Core Radiator - No Frame - With Oil Coolers (Driver Side - Engine Oil Cooler with ¾” ORB Fittings on 7” [177.8mm] centers and Passenger Side - Transmission Oil Cooler with 1 1/16” ORB Fittings on 18” [457.2mm] centers) - With Filler Neck (Passenger Side top corner), 1/8” NPT Low Coolant Sensor Fitting, and ¾” NPT Low Coolant Sensor Fitting..

Product Option Descriptions

Plastic Tank/ Aluminum Core Radiator - No Frame - With Oil Coolers (Driver Side - Engine Oil Cooler with ½“ Quick Connect Fittings on 10” [254.0mm] centers and Passenger Side - Transmission Oil Cooler with 1 1/16” ORB Fittings on 18” [457.2mm] centers) - With Filler Neck (Passenger Side top corner), 1/8” NPT Low Coolant Sensor Fitting, and ¾” NPT Low Coolant Sensor Fitting

DR-CG-2301-002-B-PT

Plastic Tank/ Aluminum Core Radiator - No Frame - With Oil Coolers (Driver Side - Engine Oil Cooler with ¾” ORB Fittings on 7” [177.8mm] centers and Passenger Side - Transmission Oil Cooler with 1 1/16” ORB Fittings on 18” [457.2mm] centers) - With Filler Neck (Passenger Side top corner) and ¾” NPT Low Coolant Sensor Fitting

DR-CG-2305-002-B-PT

Plastic Tank/ Aluminum Core Radiator - No Frame - With Oil Cooler (Driver Side - Engine Oil Cooler with ½“ Quick Connect Fittings on 10” [254.0mm] centers) - With Filler Neck (Passenger Side top corner), Low Coolant Sensor Fitting and Plug, ¾” NPT Low Coolant Sensor Fitting, and Ø1 5/16” [33.3mm] OD Inlet and Outlet Connections

DR-CG-2310-002-B-PT

Plastic Tank/ Aluminum Core Radiator - No Frame - With Oil Cooler (Driver Side - Engine Oil Cooler with ½“ Quick Connect Fittings on 10” [254.0mm] centers) - With Filler Neck (Passenger Side top corner), Low Coolant Sensor Fitting and Plug, ¾” NPT Low Coolant Sensor Fitting, and Ø2” [50.8mm] OD Inlet and Outlet Connections

DR-CG-2311-002-B-PT

Warranty

North American wide coverage.

Dura-Lite’s warranty is not prorated and warrants the original vehicle installation for a period of 1 (one) year from the date of installation (unlimited mileage) that its Radiators (the “Radiator”) will remain free from defects in material and workmanship under normal on-highway operating conditions.

All products are tested to be 100% leak free before they leave the manufacturing facility.

Read more...

Product Specifications

Core Dimension - Header to Header:

Core Dimension - Over Sidepieces:

Inlet Connection OD Dimension:

Inlet Connection Note:

Outlet Connection OD Dimension:

Outlet Connection Note:

31 7/16" 24 5/16" 2" OD 2" OD
Check Stock
Live Chat or Call us for Availability at (800) 661-1117
LOGIN/REGISTER FOR PRICING
Register Now For Immediate Access To Pricing
Available Inventory by Location:
Inventory may be Available in Canada. Live Chat or Call us at (800) 661-1117
Can't find what you are looking for? Live Chat or Call us at (800) 661-1117
Features:
  • Reinforced headers and an extra stiffening plate, which prevents leaks from happening between the tank and header and tubes and header.
  • Stronger fiber-reinforced tanks that prevent stress cracking that can happen with less flexible plastic-tank radiators.
  • Meets or exceeds original equipment (OE) heat transfer performance.
  • Headers include extra deep crimp tabs, reinforced tank crimp area on the tanks and extra stainless-steel outer crimp strips used to reinforce applications with traditional style crimp designs.
Vehicle Makes:

CHEVROLET/GMC

Vehicle Make/Model/Year:
Hide Fitments

Year “9999” refers to an “Unknown” Year.
